Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
1 / 5
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System
Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System

Hcvac Titanium Nitride Gold PVD Ion Plating Equipment, Vacuum Gold Plating System

Customization: Available
After-sales Service: Free Installing and Training, Technical Support
Warranty: One Year Limited Warranty
Send Inquiry

Product Description

Basic Info.
Model NO.
LH-
Type
PVD Vacuum Coating Machine
Coating
Vacuum Coating
Substrate
Steel
Certification
CE, ISO
Condition
New
Product
Ion Plating Equipment
Business Type
Manufacturer/Supplier
Structure
Vertical, Single Door
Control System
Manual Automatic All-in-One
Operating System
PLC Touching Screen
Coating Color
Gold, Rosegold, Silver, Black, Blue Ect
Chamber Material
Stainless Steel
Transport Package
Wooden Package
Specification
800*1000mm, 1200*1500mm, 1400*1600mm, 1600*1800mm
Origin
China, Guangdong
Product Description

MAKE YOUR WORLD MORE BEAUTIFUL

Titanium nitride gold PVD ion plating equipment, Vacuum gold plating system

PVD Ion plating equipment is a ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, and large productive capacity.

Characteristic: The principle of the electric arc is integrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.

Applied industry: PVD Ion plating equipment can be used to coat metal film, titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film. It is a highly efficient multi-functional coating equipment.

  • Ultra-hard coating for tools and moulds
  • Decorative coating for car wheels and ceramics
  • Golf products, watches, and hotel products
  • Sanitary ware, luminaires, and optical frames
  • Hardware and various metal accessories

Equipment Overview:

PVD Ion Plating Equipment

Samples Coated by the System:

Coating Sample 1
Coating Sample 2
Coating Sample 3
Coating Sample 4
Coating Sample 5
Technical Specifications
Model Dimension LH-800 LH-1250 LH-1416 LH-1618
Chamber Size 800*1000mm 1200*1500mm 1400*1600mm 1600*1800mm
Main Configuration Eight multi-arc targets Twelve multi-arc targets Fourteen multi-arc targets Twenty multi-arc targets
Power Source Electric-arc power, Filament power, Pulsed bias power supply
Process Gas Control Mass flowmeter + Electromagnetic ceramic valve
Chamber Structure Vertical side opening door, pump system postposition, double water cooling
Vacuum System Molecule/Diffusion pump + Roots pump + Mechanical pump (Up to 5.0*10 -5 Pa)
Baking Temperature Normal to 350°C PID control, radiation heating
Workpiece Motion Public rotation Frequency control: 0-20 RPM
Control Mode Manual / Automatic / PLC + HMI / PC
Frequently Asked Questions
What types of colors can this PVD coating machine produce?
The system can produce a wide range of decorative colors including Gold, Rose Gold, Silver, Black, Blue, and more, depending on the coating materials used.
Is the PVD ion plating process environmentally friendly?
Yes, this equipment is designed to be highly efficient, harmless, and pollution-free, making it an eco-friendly choice for industrial coating.
What materials can be used as substrates for coating?
The machine is versatile and can coat both metal surfaces (like steel, titanium, nickel, chromium, and copper) as well as non-metal surfaces.
How is the vacuum system controlled?
The machine features a PLC Touching Screen operating system with multiple control modes, including Manual, Automatic, and PC integration for precise operation.
Can the equipment dimensions be customized?
Yes, we can design the dimensions of the equipment according to the customer's specific technical requirements and production needs.
What industries commonly use this ion plating equipment?
It is extensively used in fields requiring ultra-hard coatings for tools and decorative coatings for automotive parts, ceramics, watches, sanitary ware, and hardware.
