The ground mounting bracket is strictly designed according to the maximum wind speed, maximum snow load, solar panel specifications, and other design schemes. While ensuring sufficient strength, installation efficiency and labor costs are optimized. The service life of the bracket is engineered for long-term durability. Support foundations include direct ground entry, ground screws, and cement piers.
The double column system can utilize ground bolt columns or piling columns. Ground screw posts allow for precise height adjustments, while piling columns offer higher strength for various terrains.
Step 1: Installing Ground Screws - Anchor the support structure using specialized drilling equipment to a depth sufficient for the system's weight.
Step 2: Rail & Panel Installation - Attach supporting rails using brackets and bolts, ensuring they are level before fastening the solar panels securely.
| Material | Mg-Al-Zn & AL-6005-T5 (Anodized) / SUS304 Components |
| Application | Commercial and Residential Installation |
| Tilt Angle | 0 - 60° |
| Wind Speed | 0 - 60 m/s |
| Snow Load | 0 - 150 cm |
| Ground Clearance | 0 - 1 m |
| Design Standard | AS/NZS 1170, DIN 1055, JIS C8955: 2017, IBC 2009 |
| Warranty | 12 Years |
The facility features professional processing workshops for both aluminum alloy and steel materials. Independent production lines handle cutting, drilling, stamping, and forging to meet high customization and precision requirements.
With 6 dedicated production lines for Magnesium Aluminum Zinc and steel materials, the monthly productivity reaches 40-50MW, ensuring timely delivery for large-scale projects.
